功能
|
檔位
|
解析度
|
測量範圍
|
精確度
|
|
接地電阻(自動量程)
|
20Ω
|
0.01Ω*
|
0.00 - 20.99Ω
|
|±1.5%±0.05Ω
|
|
200Ω
|
0.1Ω
|
16.0 - 99.9Ω
|
|±2%±0.5Ω
|
|
100.0 - 209.9Ω
|
|±3%±2Ω
|
|
1500Ω
|
1Ω
|
160 - 399Ω
|
|±5%±5Ω
|
|
400 - 599Ω
|
|±10%±10Ω
|
|
10Ω
|
600 - 1580Ω
|
---
|
|
AC 電流(50Hz / 60Hz)
(自動量程)
|
100mA
|
0.1mA
|
0.0 - 104.9mA
|
|±2%±0.7mA
|
|
1000mA
|
1mA
|
80 - 1049mA
|
|±2%
|
|
10A
|
0.01A
|
0.80 - 10.49A
|
|
30A
|
0.1A
|
8.0 - 31.5A
|
|
操作系統
|
|
Earth resistance function :
|
Constant voltage injection,Current detection,
(Frequency: Approx.2400Hz)Dual Integration
|
|
AC current function :
|
Successive Approximation
|
|
|
過載顯示
|
"OL" is displayed when input exceeds the upper limit of a measuring range
|
|
響應時間
|
Approx.7 seconds (Earth resistance)
Approx.2 seconds (AC current)
|
|
取樣率
|
Approx. 1 times per second
|
|
電源
|
DC6V : R6 (sizeAA manganese battery) × 4pcs,
or LR6 (sizeAA alkaline battery) × 4pcs
|
|
耗電量
|
Approx. 50mA (max. 100mA)
|
|
測量時間
|
Approx. 12 hours (when R6 is used)
Approx. 24 hours (when LR6 is used)
|
|
自動關機
|
Turns power off about 10 minutes after the last button operation.
|
|
安全規範
|
IEC 61010-1 : 2001 (CAT IV 300V Pollution degree2)
|
|
耐壓
|
AC5320Vrms / 5 seconds
Between the Transformer jaws fitted parts and Case enclosure
(except for jaws)
|
|
測量導線尺寸
|
Approx. 32mm max.
|
|
尺寸
|
246(L) × 120(W) × 54(D)mm
|
|
重量
|
Approx. 780g (including batteries)
|
|
其他配件
|
Battery R6 (AA) × 4, Instruction manual
8304 (Resister for operation check)
9166 (Hard case)
|
